Ryan Bigg

The official documentation for the graphql-ruby gem recommends this code for a mutation class that can either succeed or fail:

class Mutations::CreateComment < Mutations::BaseMutation
  argument :body, String
  argument :post_id, ID

  field :comment, Types::Comment
  field :errors, [String], null: false

  def resolve(body:, post_id:)
    post = Post.find(post_id)
    comment = post.comments.build(body: body, author: context[:current_user])
    if comment.save
      # Successful creation, return the created object with no errors
      {
        comment: comment,
        errors: [],
      }
    else
      # Failed save, return the errors to the client
      {
        comment: nil,
        errors: comment.errors.full_messages
      }
    end
  end
end

I’d like to show an alternative to this that I think leads to cleaner code by using GraphQL concept called union types.

We use union types in GraphQL when we want a field to return one or more distinct types as its result. In the case of the above comment mutation, the two types of things we would like to return are either:

Let’s change that mutation above to use a union type by declaring the type at the top of the mutation, and removing the two fields:

class Mutations::CreateComment < Mutations::BaseMutation
  type Types::CreateCommentResult
  argument :body, String
  argument :post_id, ID

  def resolve(body:, post_id:)
    post = Post.find(post_id)
    comment = post.comments.build(body: body, author: context[:current_user])
    if comment.save
      # Successful creation, return the created object with no errors
      {
        comment: comment,
        errors: [],
      }
    else
      # Failed save, return the errors to the client
      {
        comment: nil,
        errors: comment.errors.full_messages
      }
    end
  end
end

This new type will be our union type that will represent either a successful creation for a comment, or a failed one.

We can define this type in our types directory under graphql, in a file called create_comment_result.rb:

module Types
  class CreateCommentResult < BaseUnion
    description "The result from attempting to create a comment"
    possible_types Types::Comment, Types::Errors

    def self.resolve_type(object, _context)
      if object[:comment]
        [Types::Comment, object[:comment]]
      else
        [Types::Errors, object]
      end
    end
  end
end

A union type is defined by first inheriting from BaseUnion. If we had common logic to share between union types in our GraphQL API, that logic would go into BaseUnion.

Inside this CreateCommentResult type itself, we provide a description that’ll appear in our API documentation, and inform this class what the possible types are. For this union type, we’re defining two possible types: Types::Comment, and Types::Errors.

When the GraphQL code runs, it will call this resolve_type method to determine the correct GraphQL type to use when representing the result of the mutation. This method checks if object[:comment] is present, and if it is the type that’ll be used is a Types::Comment, and we can fetch the comment from that object using object[:comment]. In Rails parlance, this object[:comment] will be an instance of the Comment model – a result of a successful build and save.

If the operation was to fail, we would instead return a Types::Error type, and use the resulting object as the base object for that type.

These two types can be defined in the types directory too. Let’s look at CommentType first, defined in types/comment.rb:

class Types::Comment < Types::BaseObject
  field :id, ID, null: false
  field :body, String, null: false
end

This type is used to represent comments in our GraphQL API. It provides access to both the id and body attributes from any Comment instance that is represented by this API.

Then, the Errors type:

class Types::Errors < Types::BaseObject
  field :errors, [String], null: false
end

This type represents the { comment: nil, errors: [...] } hash that will be returned when a comment creation fails.

With these union types setup, we can write this GraphQL query that will rely on them:

mutation {
  createComment(input: { postId: 1, body: "Hello world" }) {
    __typename
    ... on Comment {
      id
    }

    ...on Errors {
      errors
    }
  }
}

Firstly, we call this mutation by passing in its required arguments. After that, we fetch a field called __typename. This field is automatically defined, and it will return the type whatever object is returned, either Comment or Errors. When calling this GraphQL API, we can use __typename to determine how to act.

The ... on syntax here tells GraphQL which fields we would like to use in the case of each part of the union being returned here. If it’s a comment, we will fetch just the id. If it’s Errors, we can fetch just the errors.

If we were to call this mutation with an empty comment body, we would see this as the result:

{
  "data": {
    "createComment": {
      "__typename": "Errors",
      "errors": [
        "Body can't be blank"
      ]
    }
  }
}

And if we were to call it with a valid body, we would see this:

{
  "data": {
    "createComment": {
      "__typename": "Comment",
      "id": "6"
    }
  }
}

When using this API (for example, within a frontend codebase), we can assert on __typename to determine how to show the result to a user – if it’s a Comment, then indicate a successful comment creation. If it’s Errors, then show those errors on the form.
